• Socket: AMD Socket AM5
• Chipset: AMD B650

CPU Support

• Supported Processors:
  • AMD Ryzen™ 7000, Ryzen™ 8000, and Ryzen™ 9000 Series Processors
  • (Visit GIGABYTE's website for the latest CPU support list.)

Memory

• Memory Type: DDR5
• Supported Speeds:
  • 6400(OC), 6200(OC), 6000(OC), 5600(OC), 5200, 4800, 4400 MT/s
• Memory Slots: 2 x DDR5 DIMM sockets
• Maximum Capacity: Up to 128 GB (64 GB single DIMM capacity)
• Architecture: Dual channel memory
• Memory Support:
  • Non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16
  • AMD EXPO™ and Extreme Memory Profile (XMP) support
  • (Refer to the "Memory Support List" on GIGABYTE's website for more information.)

Onboard Graphics

• Integrated Graphics:
  • D-Sub Port: Max resolution of 1920x1200@60 Hz
  • DisplayPort: Max resolution of 3840x2160@144 Hz (DisplayPort 1.4)
  • HDMI Port: Max resolution of 4096x2160@60 Hz (HDMI 2.1)
• Display Support: Up to 3 displays simultaneously

Audio

• Audio Codec: Realtek® Audio CODEC
• Audio Channels: 2/4/5.1/7.1-channel
• S/PDIF Out: Supported

LAN

• LAN Chip: Realtek® GbE LAN (1 Gbps/100 Mbps/10 Mbps)

Expansion Slots

• CPU:
  • 1 x PCI Express x16 slot (PCIEX16)
    • AMD Ryzen™ 7000 Series: PCIe 4.0 x16 mode
    • AMD Ryzen™ 8000 Series-Phoenix 1: PCIe 4.0 x8 mode
    • AMD Ryzen™ 8000 Series-Phoenix 2: PCIe 4.0 x4 mode
• Chipset:
  • 1 x PCI Express x1 slot (PCIEX1, supports PCIe 3.0)

Storage Interface

• M.2 Connector:
  • 1 x M.2 (M2A_CPU), supporting Socket 3, M key, type 2580/2280 SSDs
    • AMD Ryzen™ 7000 Series: PCIe 4.0 x4/x2 SSDs
    • AMD Ryzen™ 8000 Series-Phoenix 1: PCIe 4.0 x4/x2 SSDs
    • AMD Ryzen™ 8000 Series-Phoenix 2: PCIe 4.0 x4/x2 SSDs
• SATA Connectors: 4 x SATA 6Gb/s
• RAID Support:
  • RAID 0, RAID 1, and RAID 10 for both NVMe SSD and SATA storage devices

USB Ports

• CPU:
  • 2 x USB 3.2 Gen 1 ports (back panel)
  • 1 x USB 2.0/1.1 port (back panel)
• Chipset:
  • 2 x USB 3.2 Gen 1 ports (internal)
  • 7 x USB 2.0/1.1 ports (3 ports on back panel, 4 internal)

Internal I/O Connectors

• Power Connectors: 1 x 24-pin ATX, 1 x 8-pin ATX 12V
• Fan Headers:
  • 1 x CPU fan header
  • 2 x system fan headers
• RGB Headers: 1 x addressable LED strip header, 1 x RGB LED strip header
• M.2 and SATA Connectors: As specified above
• USB Headers: Various USB headers as specified
• Trusted Platform Module Header: Yes
• Clear CMOS Jumper: Yes

Back Panel Connectors

• Ports:
  • 4 x USB 2.0/1.1 ports
  • 1 x PS/2 keyboard/mouse port
  • 1 x D-Sub port
  • 1 x Q-Flash Plus button
  • 2 x USB 3.2 Gen 1 ports
  • 1 x DisplayPort
  • 1 x HDMI port
  • 1 x RJ-45 port
  • 3 x audio jacks

BIOS

• Flash Memory: 256 Mbit
• BIOS Type: AMI UEFI BIOS

Unique Features

• Support: GIGABYTE Control Center (GCC), Q-Flash, Q-Flash Plus
• Bundled Software: Norton® Internet Security (OEM version), LAN bandwidth management software

Operating System

• Supported OS: Windows 11 64-bit, Windows 10 64-bit

Form Factor

• Form Factor: Micro ATX (23.0 cm x 22.5 cm)
