GPU & Architecture

• GPU: NVIDIA GeForce RTX 5060

• Architecture: NVIDIA Blackwell

• CUDA Cores: ~3,840

Clock Speeds (Factory OC)

• Base Clock: ~2.28 GHz

• Boost Clock: up to ~2.53 GHz (OC)

Memory

• Memory Size: 8 GB

• Memory Type: GDDR7

• Memory Interface: 128-bit

• Memory Bandwidth: ~448 GB/s

Interface & Power

• Bus Interface: PCI Express 5.0 x8

• Total Board Power (TDP): ~145 W

• Power Connector: 1 × 8-pin

• Recommended PSU: 550 W

Display Outputs

• 3 × DisplayPort 2.1b

• 1 × HDMI 2.1b

• Max Resolution:

  • Up to 8K (with DSC)

  • High-refresh 4K supported

Cooling & Design

• Cooling: Dual-fan (PNY Dual OC design)

• Form Factor: Dual-slot

• Backplate: Yes (model-dependent)

NVIDIA Features

• DLSS 4 (Multi-Frame Generation)

• Ray Tracing (4th-gen RT Cores)

• Tensor Cores (5th-gen)

• NVIDIA Reflex 2

• NVIDIA Broadcast & Studio support
